Centrifugal Upblast, High Speed Direct Drive Exhaust Fan, Single Phase with Speed Control, 600-1000 CFM (VXD33)

Brand: VENTILATION DIRECT

Color: Aluminum

Features:

• High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control (single phase only), disconnect switch and 11-3/4" wheel. Base Size 21" x 21".
• Exhaust Fan handles 600-1000 CFM @ -0.500" wc ESP, Fan runs at 1575 RPM
• Exhaust Motor: 0.333 HP, 1 Phase 115 V, 60Hz, 4.1 FLA, ODP (Open Drip Proof)
• UL705, UL762, & ULC-S645 Rated
• Manufactured in the USA. One year warranty. Technical support available upon purchase. As all fans are custom built, no returns or exchanges are accepted.

model number: VXD33

Part Number: Upblast Direct Drive Exhaust

Details: High Speed Direct Drive Centrifugal Upblast Exhaust Fan with speed control (single phase only), disconnect switch and 11-3/4" wheel. Base Size 21" x 21". Exhaust Fan handles 600-1000 CFM @ -0.500" wc ESP, Fan runs at 1575 RPM. Exhaust Motor: 0.333 HP, 1 Phase 115 V, 60Hz, 4.1 FLA, ODP (Open Drip Proof). UL705, UL762, & ULC-S645 Rated. Manufactured in the USA. One year warranty. Technical support available upon purchase. As all fans are custom built, no returns or exchanges are accepted.

EAN: 0735202104644
